Precision Electrothermal MOSFET models

Validating circuit designs when using Power MOSFETs can be a challenging process. Accurate modelling of the dynamic characteristics of the device is key to EMI consideration. If the model is not realistic, EMC problems cannot be recognized thereby causing issues down the line, likely when the designer has already committed to layout.

With Nexperia's new electrothermal MOSFET model, the engineer is provided the capability to validate their circuit design during the preliminary stage of the project.

Below is a list of products that have the electro thermal models available, you can find the models in the support tab.

Type number	Package version	Package name	Channel type	VDS [max] (V)	RDSon [max] @ VGS = 10 V (mΩ)	RDSon [max] @ VGS = 4.5 V (mΩ)	Tj [max] (°C)	ID [max] (A)	Automotive qualified	Rth(j-mb) [max] (K/W)
BUK7J1R0-40H	SOT1023	LFPAK56E; Power-SO8	N	40	1		175	220	Y	0.3
BUK7J1R4-40H	SOT1023	LFPAK56E; Power-SO8	N	40	1.4		175	190	Y	0.38
BUK7M3R3-40H	SOT1210	LFPAK33	N	40	3.3		175	80	Y	1.48
BUK7M4R3-40H	SOT1210	LFPAK33	N	40	4.3		175	95	Y	1.67
BUK7M5R0-40H	SOT1210	LFPAK33	N	40	5		175	85	Y	1.81
BUK7M6R0-40H	SOT1210	LFPAK33	N	40	6		175	50	Y	2.14
BUK7M6R7-40H	SOT1210	LFPAK33	N	40	6.7		175	50	Y	2.32
BUK7M8R5-40H	SOT1210	LFPAK33	N	40	8.5		175	40	Y	2.56
BUK7M9R5-40H	SOT1210	LFPAK33	N	40	9.5		175	40	Y	2.74
BUK7M11-40H	SOT1210	LFPAK33	N	40	11		175	35	Y	3
BUK7M15-40H	SOT1210	LFPAK33	N	40	15		175	30	Y	3.44
BUK7M20-40H	SOT1210	LFPAK33	N	40	20		175	25	Y	3.96
BUK7S0R5-40H	SOT1235	LFPAK88	N	40	0.55		175	500	Y	0.4
BUK7S0R7-40H	SOT1235	LFPAK88	N	40	0.7		175	425	Y	0.4
BUK7S1R0-40H	SOT1235	LFPAK88	N	40	1		175	325	Y	0.4
BUK7S1R2-40H	SOT1235	LFPAK88	N	40	1.2		175	300	Y	0.51
BUK7S1R5-40H	SOT1235	LFPAK88	N	40	1.5		175	260	Y	0.62
BUK7S2R0-40H	SOT1235	LFPAK88	N	40	2		175	190	Y	0.82
BUK7S2R5-40H	SOT1235	LFPAK88	N	40	2.51		175	140	Y	1.11
BUK7Y1R7-40H	SOT669	LFPAK56; Power-SO8	N	40	1.7		175	120	Y	0.51
BUK7Y2R0-40H	SOT669	LFPAK56; Power-SO8	N	40	2		175	120	Y	0.69
BUK7Y2R5-40H	SOT669	LFPAK56; Power-SO8	N	40	2.5		175	120	Y	0.79
BUK7Y3R0-40H	SOT669	LFPAK56; Power-SO8	N	40	3		175	120	Y	0.87
BUK7Y3R5-40H	SOT669	LFPAK56; Power-SO8	N	40	3.5		175	120	Y	1.3
BUK9J0R9-40H	SOT1023	LFPAK56E; Power-SO8	N	40	0.94	1.2	175	220	Y	0.3
BUK9M3R3-40H	SOT1210	LFPAK33	N	40	3.3	4.2	175	80	Y	1.48
BUK9M4R3-40H	SOT1210	LFPAK33	N	40	4.3	5.5	175	95	Y	1.67
BUK9M5R0-40H	SOT1210	LFPAK33	N	40	5	6.4	175	85	Y	1.81
BUK9M6R0-40H	SOT1210	LFPAK33	N	40	6	7.7	175	50	Y	2.14
BUK9M6R7-40H	SOT1210	LFPAK33	N	40	6.7	8.6	175	50	Y	2.32
BUK9M8R5-40H	SOT1210	LFPAK33	N	40	8.5	11	175	40	Y	2.56
BUK9M9R5-40H	SOT1210	LFPAK33	N	40	9.5	12	175	40	Y	2.74
BUK9M11-40H	SOT1210	LFPAK33	N	40	11	14	175	35	Y	3
BUK9M15-40H	SOT1210	LFPAK33	N	40	15	19	175	30	Y	3.44
BUK9M20-40H	SOT1210	LFPAK33	N	40	20	25	175	25	Y	3.96
BUK9Y1R3-40H	SOT669	LFPAK56; Power-SO8	N	40	1.3	1.8	175	190	Y	0.38
BUK9Y1R6-40H	SOT669	LFPAK56; Power-SO8	N	40	1.6	2.2	175	120	Y	0.51
BUK9Y1R9-40H	SOT669	LFPAK56; Power-SO8	N	40	1.9	2.6	175	120	Y	0.69
BUK9Y2R4-40H	SOT669	LFPAK56; Power-SO8	N	40	2.4	3.2	175	120	Y	0.79
BUK9Y2R8-40H	SOT669	LFPAK56; Power-SO8	N	40	2.8	3.9	175	120	Y	0.87
