Counters / frequency dividers

Logic devices you can always count on!

Ideal in simple timing applications, binary counters can be used to generate clock signals, frequency divide external clock signals or initiate events after a preset number of clock pulses. Based on low power CMOS technology, our efficient solutions feature integrated oscillator and TTL compatible inputs.

Key features and benefits

  • Clock generation
  • Clock division
  • Integrated oscillator
  • Low power cmos
  • TTL compatible inputs
  • AEC-Q100 grade 1

Key applications

  • Automotive timing applications

Parametric search

Counters / frequency dividers
Please wait loading data...
Parametric search is unavailable.

Products

Type number Description Status Quick access
74HC(T)163-Q100 Presettable synchronous 4-bit binary counter; synchronous reset ACT
74HC163D-Q100 Presettable synchronous 4-bit binary counter; synchronous reset Production
74HC163PW-Q100 Presettable synchronous 4-bit binary counter; synchronous reset Production
74HCT163D-Q100 Presettable synchronous 4-bit binary counter; synchronous reset Production
74HCT163PW-Q100 Presettable synchronous 4-bit binary counter; synchronous reset Production
74HC(T)193-Q100 Presettable synchronous 4-bit binary up/down counter ACT
74HC193D-Q100 Presettable synchronous 4-bit binary up/down counter Production
74HC193DB-Q100 Presettable synchronous 4-bit binary up/down counter Production
74HC193PW-Q100 Presettable synchronous 4-bit binary up/down counter Production
74HCT193D-Q100 Presettable synchronous 4-bit binary up/down counter Production
74HCT193DB-Q100 Presettable synchronous 4-bit binary up/down counter Production
74HCT193PW-Q100 Presettable synchronous 4-bit binary up/down counter Production
74HC(T)393-Q100 Dual 4-bit binary ripple counter ACT
74HC393BQ-Q100 Dual 4-bit binary ripple counter Production
74HC393D-Q100 Dual 4-bit binary ripple counter Production
74HC393PW-Q100 Dual 4-bit binary ripple counter Production
74HCT393BQ-Q100 Dual 4-bit binary ripple counter Production
74HCT393D-Q100 Dual 4-bit binary ripple counter Production
74HCT393PW-Q100 Dual 4-bit binary ripple counter Production
74HC(T)4017-Q100 Johnson decade counter with 10 decoded outputs ACT
74HC4017BQ-Q100 Johnson decade counter with 10 decoded outputs Production
74HC4017D-Q100 Johnson decade counter with 10 decoded outputs Production
74HC4017PW-Q100 Johnson decade counter with 10 decoded outputs Production
74HCT4017BQ-Q100 Johnson decade counter with 10 decoded outputs Production
74HCT4017D-Q100 Johnson decade counter with 10 decoded outputs Production
74HC(T)4020-Q100 14-stage binary ripple counter ACT
74HC4020BQ-Q100 14-stage binary ripple counter Production
74HC4020D-Q100 14-stage binary ripple counter Production
74HC4020PW-Q100 14-stage binary ripple counter Production
74HCT4020BQ-Q100 14-stage binary ripple counter Production
74HCT4020D-Q100 14-stage binary ripple counter Production
74HCT4020PW-Q100 14-stage binary ripple counter Production
74HC(T)4040-Q100 12-stage binary ripple counter ACT
74HC4040BQ-Q100 12-stage binary ripple counter Production
74HC4040D-Q100 12-stage binary ripple counter Production
74HC4040DB-Q100 12-stage binary ripple counter Production
74HC4040PW-Q100 12-stage binary ripple counter Production
74HCT4040BQ-Q100 12-stage binary ripple counter Production
74HCT4040D-Q100 12-stage binary ripple counter Production
74HCT4040DB-Q100 12-stage binary ripple counter Production
74HCT4040PW-Q100 12-stage binary ripple counter Production
74HC(T)4060-Q100 14-stage binary ripple counter with oscillator ACT
74HC4060BQ-Q100 14-stage binary ripple counter with oscillator Production
74HC4060D-Q100 14-stage binary ripple counter with oscillator Production
74HC4060DB-Q100 14-stage binary ripple counter with oscillator Production
74HC4060PW-Q100 14-stage binary ripple counter with oscillator Production
74HCT4060BQ-Q100 14-stage binary ripple counter with oscillator Production
74HCT4060D-Q100 14-stage binary ripple counter with oscillator Production
74HC(T)4520-Q100 Dual 4-bit synchronous binary counter ACT
74HC4520D-Q100 Dual 4-bit synchronous binary counter Production
74HCT4520D-Q100 Dual 4-bit synchronous binary counter Production
74HC161-Q100 Presettable synchronous 4-bit binary counter; asynchronous reset ACT
74HC161D-Q100 Presettable synchronous 4-bit binary counter; asynchronous reset Production
74HC161PW-Q100 Presettable synchronous 4-bit binary counter; asynchronous reset Production
74HC4024-Q100 7-stage binary ripple counter ACT
74HC4024D-Q100 7-stage binary ripple counter Production
74LV393-Q100 Dual 4-bit binary ripple counter ACT
74LV393D-Q100 Dual 4-bit binary ripple counter Production
74LV393PW-Q100 Dual 4-bit binary ripple counter Production
74LV4060-Q100 14-stage binary ripple counter with oscillator ACT
74LV4060D-Q100 14-stage binary ripple counter with oscillator Production
74LV4060PW-Q100 14-stage binary ripple counter with oscillator Production
HEF4017BT-Q100 5-stage Johnson decade counter Production
HEF4020BT-Q100 14-stage binary counter Production
HEF4040BT-Q100 12-stage binary ripple counter Production
HEF4060BT-Q100 14-stage ripple-carry binary counter/divider and oscillator Production
HEF4520BT-Q100 Dual binary counter Production
HEF4541BT-Q100 Programmable timer Production

Brochure (1)

File name Title Type Date
Nexperia_document_brochure_Logic_Q100_portfolio_201711 AEC-Q100 automotive Logic portfolio Brochure 2017-11-16

Marcom graphics (1)

File name Title Type Date
DHVQFN14_SOT762-1_mk plastic, dual in-line compatible thermal enhanced very thin quad flat package; no leads; 14 terminals; 0.5 mm pitch; 2.5 mm x 3 mm x 0.85 mm body Marcom graphics 2017-01-28
