Resistor Equipped Transistors (RETs)

Space- and cost-saving solutions that reduce your component count and simplify circuit design

By combining transistors with their attendant resistors, RETs make excellent space- and cost-saving solutions. We offer some 400 products, so you can find the best fit for your application. Within our portfolio you will find single and dual RETs with a great variety of resistor combinations. Furthermore you can also choose from ranges with DFN and leaded SMD packages.

Key features and benefits

  • ± 10% resistance ratio tolerance
  • Reduces pick and place costs
  • Built-in bias resistors
  • Reduces component count
  • 100 mA, 500 mA and up to 600 mA output current capability
  • Simplifies circuit design

Key applications

  • Controlling IC inputs
  • Digital systems
  • Switching loads

Latest news and blogs

  • Blog article
Jan 4, 2023

Understanding the switching characteristics of RETs
  • Blog article
Jun 16, 2021

RETs deliver efficient 48 V digital switching
  • Press release
Jan 12, 2021

Nexperia leads with industry’s first 80 V RETs for ...

Latest videos

Why use Nexperia 80 V RETs in mild hybrid vehicle applications?

Why use Nexperia 80 V RETs in mild hybrid vehicle applications?
Introducing Nexperia RETs (Resistor equipped transistors)
What is a RET (Resistor equipped transistor)? Quick explanation

Parametric search

Resistor Equipped Transistors (RETs)
Please wait loading data...
Parametric search is unavailable.

Products

Type number Description Status Quick access
PDTA113E series PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm ACT
PDTA113EM PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTA113ET PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTA113EU PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTA114T series PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open ACT
PDTA114TM PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTA114TT PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTA114TU PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTA115E series PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm ACT
PDTA115EM PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115EMB PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115ET PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115EU PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115EU-Q PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115T series PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open ACT
PDTA115TM PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTA115TT PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTA115TU PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTA123E series PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm ACT
PDTA123EM PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123EMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123ET PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123EU PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123EU-Q PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123J series PNP resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ ACT
PDTA123JM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123JT 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123JU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123T series PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PDTA123TM PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTA123TT PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTA123TU PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTA123Y series PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm ACT
PDTA123YM PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm Production
PDTA123YT PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm Production
PDTA123YU PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm Production
PDTA124E PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ ACT
PDTA124EM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124ET 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124EU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124T series PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PDTA124TM PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTA124TT PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTA124TU PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTA143/114/124/144EQA series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143E series PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ ACT
PDTA143EM PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143ET PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143EU PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143X series PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ ACT
PDTA143XT 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143XU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143X/123J/143Z/114YQA series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA123JQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143X_TO_124XQB series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA123JQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA124XQB 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143ZQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143X_TO_124XQC Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA123JQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124XQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143X_TO_124XQC-Q Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA123JQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124XQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143Z series PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ ACT
PDTA143ZM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTA143ZMB PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PDTA143ZQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143ZQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143ZQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZT 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTA143ZT-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTA143ZU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTA143ZU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTA143_114_124_144EQB series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA124EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA144EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143_114_124_144EQC Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143_114_124_144EQC-Q Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143_114_124_144EQC-Q Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144T series PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open ACT
PDTA144TM PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTA144TT PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTA144TU PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTA144V series PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm ACT
PDTA144VM PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTA144VT PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTA144VU PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTA144W series PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PDTA144WM PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTA144WT PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTA144WU PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTB113Z_123Y_143XQA_SER 50 V, 500 mA PNP resistor-equipped transistors ACT
PDTB113ZQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB123YQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB143XQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB113_123_143_114EQA_SER 50 V, 500 mA PNP resistor-equipped transistors ACT
PDTB113EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB114EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB123EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB143EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB1xxxT series 500 mA, 50 V PNP resistor-equipped transistors ACT
PDTB114ET 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143ET 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143XT 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB1xxxU series 500 mA, 50 V PNP resistor-equipped transistors ACT
PDTB113EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB113ZU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB114EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB114EU-Q 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB123EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB123YU 50 V, 500 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTB123YU-Q 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143XU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTC114T series NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open ACT
PDTC114TM NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTC114TT NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTC114TU NPN resistor-equipped transistor; R1 = 10 kOhm, R2 = open Production
PDTC115T series NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open ACT
PDTC115TM NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTC115TT NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTC115TU NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTC123T series NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PDTC123TM NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC123TT NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC123TU NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC124T series NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PDTC124TM NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTC124TT NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTC124TU NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTC143/114/124/144EQA series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143X/123J/143Z/114YQA series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC123JQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143X_TO_124XQB Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC123JQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC124XQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143XQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143ZQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143X_TO_124XQB-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC123JQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124XQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143X_TO_124XQC Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC123JQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC124XQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143XQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143ZQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143X_TO_124XQC-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC123JQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124XQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQB Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQB 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143EQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC144EQB 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQB-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQC Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC124EQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143EQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC144EQC 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQC-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144T series NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open ACT
PDTC144TM NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTC144TT NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTC144TU NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTC144V series NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm ACT
PDTC144VM NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTC144VT NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTC144VU NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTD123Y series NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm ACT
PDTD123YQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD123YT 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTD123YT-Q 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTD123YU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD1xxxT series 500 mA, 50 V NPN resistor-equipped transistors ACT
PDTD114ET 50 V, 500 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTD114ET-Q 50 V, 500 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTD143ET 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTD143ET-Q 500 mA, 50 V NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTD143XT 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTD1xxxU series 500 mA, 50 V NPN resistor-equipped transistors ACT
PDTD113EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD113ZU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD114EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD114EU-Q 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD123EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD123EU-Q 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD123YU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD143EU 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTD143EU-Q 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTD143XU 50 V, 500 mA NPN resistor-equipped transistor Production
PEMB13; PUMB13 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ ACT
PEMB13 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PEMB14; PUMB14 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open ACT
PUMB14 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PEMB15; PUMB15 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ ACT
PUMB15 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PEMB16; PUMB16 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm ACT
PUMB16 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm Production
PEMB17; PUMB17 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PEMB17 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm EndOfLife
PUMB17 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PEMB18; PUMB18 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ ACT
PEMB18 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ EndOfLife
PUMB18 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PEMB19; PUMB19 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PEMB19 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open EndOfLife
PUMB19 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PEMB1; PUMB1 PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ ACT
PEMB1 PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ EndOfLife
PUMB1 PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ Production
PEMB30; PUMB30 PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PEMB30 PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open EndOfLife
PUMB30 PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PEMB4; PUMB4 PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open ACT
PEMB4 PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open EndOfLife
PUMB4 PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PEMD12; PUMD12 NPN/PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ ACT
PUMD12 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PEMD17; PUMD17 NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PEMD17 NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm EndOfLife
PUMD17 50 V, 100 mA NPN/PNP resistor-equipped double transistors; R1 = 47 kΩ, R2 = 22 kΩ Production
PEMD18; PUMD18 NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ ACT
PUMD18 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PEMD19; PUMD19 NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PEMD19 NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open EndOfLife
PUMD19 NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PEMH17; PUMH17 NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PEMH17 NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm EndOfLife
PUMH17 NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PEMH24; PUMH24 NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm ACT
PUMH24 NPN/NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PEMH30; PUMH30 NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PUMH30 NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = open Production
PEMH7; PUMH7 NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open ACT
PEMH7 NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open EndOfLife
PUMH7 NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open Production
PEMH9; PIMH9; PUMH9 NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ ACT
PEMH9 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PIMH9 NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PUMH9 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PUMH9-Q 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
NHDTA114ET 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114ET-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114EU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114EU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114YT 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114YT-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114YU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114YU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA123JT 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA123JT-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA123JU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA123JU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA124ET 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA124ET-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA124EU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA124EU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA143ZT 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA143ZT-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA143ZU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA143ZU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA144ET 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA144ET-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA144EU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA144EU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTC114ET 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114ET-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114EU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114EU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YT 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YT-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC123JT 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC123JT-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC123JU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC123JU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC124ET 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC124ET-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC124EU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC124EU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC143ZT 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC143ZT-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC143ZU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC143ZU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC144ET 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC144ET-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC144EU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC144EU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMB1 80 V, 100 mA PNP/PNP resistor-equipped double transistors Qualification
NHUMB10 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB10-Q 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB11 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB13 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB13-Q 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB2 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB9 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB9-Q 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMD10 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD10-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD12 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD12-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD13 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD13-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD2 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD2-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD3 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD3-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD9 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD9-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMH1 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH1-Q 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH10 80 V, 100 mA NPN/NPN resistor-equipped double transistor Production
NHUMH10-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMH11 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH11-Q 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH13 80 V, 100 mA NPN/NPN resistor-equipped double transistor Production
NHUMH13-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMH2 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH2-Q 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH9 80 V, 100 mA NPN/NPN resistor-equipped double transistor Production
NHUMH9-Q 80 V, 100 mA NPN resistor-equipped transistors Production
PBRN113EK EndOfLife
PBRN113ES EndOfLife
PBRN113ET 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PBRN113ET-Q 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PBRN113ZT 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PBRN113ZT-Q 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PBRN123ET 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PBRN123ET-Q 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PBRN123YT 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PBRN123YT-Q 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PBRP113ET 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PBRP113ET-Q 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PBRP113ZT 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PBRP113ZT-Q 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PBRP123ET 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PBRP123ET-Q 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PBRP123YT 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PBRP123YT-Q 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTA113EMB PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 1 kΩ Production
PDTA113ZM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA113ZM-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA113ZMB PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA113ZT 50 V, 100 mA PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA113ZT-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA113ZU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA113ZU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA114EM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTA114EMB 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTA114EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA114ET 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTA114ET-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTA114EU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTA114EU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTA114TMB PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = open Production
PDTA114YM PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YMB PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA114YT PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YT-Q 50 V, 100 mA PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YU PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YU-Q PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA115TMB PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = open Production
PDTA123JMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123JQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA123TMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = open Production
PDTA123YMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTA123YQB 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ Production
PDTA123YQB-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ Production
PDTA124EMB PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124ET-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124EU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124TMB PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = open Production
PDTA124XM PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA124XMB PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA124XQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124XT PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA124XT-Q PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA124XU PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA143EMB PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143TM PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTA143TMB 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTA143TT 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTA143TU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTA143TU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTA143XM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143XM-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143XMB PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143XQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EM 50 V, 100 mA PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144EM-Q PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144EMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144ET PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144ET-Q PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144EU 50 V, 100 mA PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144EU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144TMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PDTA144VMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 10 kΩ Production
PDTA144WMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTB113ET PNP 500 mA, 50 V resistor-equipped transistor; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTB113ZT PNP 500 mA, 50 V resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTB123ET PNP 500 mA, 50 V resistor-equipped transistor; R1 = 2.2 kOhm, R2 = 2.2 kOhm Production
PDTB123TT PNP 500 mA, 50 V resistor-equipped transistor; R1 = 2.2 kOhm, R2 = open Production
PDTB123YT 50 V, 500 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTB123YT-Q 50 V, 500 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTB143ET-Q 50 V, 500 mA PNP resistor-equipped transistor Production
PDTC114EM 50 V, 100 mA NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC114EM-Q 50 V, 100 mA NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC114EMB NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC114ET 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC114ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC114EU NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC114TMB NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open Production
PDTC114YM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC114YMB NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC114YT 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC114YT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC114YU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC114YU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC115EM 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTC115EMB NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTC115ET 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTC115EU 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTC115EU-Q 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kOhm, R2 = 100 kOhm Production
PDTC115TMB NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = open Production
PDTC123EM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTC123EMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTC123ET 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTC123ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTC123EU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTC123JM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTC123JMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTC123JT 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTC123JT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTC123JU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTC123JU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTC123TMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = open Production
PDTC123YM NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC123YM-Q NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC123YMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC123YQB 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ Production
PDTC123YQB-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ Production
PDTC123YT NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC123YT-Q NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC123YU NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC123YU-Q NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC124EM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC124EMB NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC124ET 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC124ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC124EU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC124EU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC124TMB NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open Production
PDTC124XM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC124XMB NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC124XT 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC124XT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC124XU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC124XU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC143EM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7  kΩ Production
PDTC143EMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTC143ET 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7  kΩ Production
PDTC143ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7  kΩ Production
PDTC143EU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7  kΩ Production
PDTC143EU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7  kΩ Production
PDTC143TM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTC143TMB 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTC143TT 50 V, 100 mA NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = open Production
PDTC143TT-Q 50 V, 100 mA NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = open Production
PDTC143TU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTC143XM NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTC143XMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTC143XT NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTC143XU NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTC143ZM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTC143ZMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PDTC143ZT 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTC143ZT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTC143ZU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTC143ZU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ Production
PDTC144EM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC144EMB 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC144ET 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC144ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC144EU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC144EU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC144TMB NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PDTC144VMB NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 10 kΩ Production
PDTC144WM 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC144WM-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC144WMB NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC144WT 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC144WT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC144WU 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTD113EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD113ET 50 V, 500 mA NPN resistor-equipped transistor; R1 = 1 kΩ, R2 = 1 kΩ Production
PDTD113ET-Q 50 V, 500 mA NPN resistor-equipped transistor; R1 = 1 kΩ, R2 = 1 kΩ Production
PDTD113ZQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD113ZT 50 V, 500 mA NPN resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTD113ZT-Q NPN 500 mA, 50 V resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTD114EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD123EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD123ET 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTD123ET-Q 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTD123TT NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTD143EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD143XQA 50 V, 500 mA NPN resistor-equipped transistors Production
PEMB10 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PEMB11 PNP/PNP resistor-equipped transistor; R1  = 10 kΩ, R2 = 10 kΩ Production
PEMB2 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PEMB20 50 V, 100 mA PNP/PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PEMB24 50 V, 20 mA PNP/PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PEMB3 50 V, 100 mA PNP/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open Production
PEMB9 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PEMD10 NPN/PNP double Resistor-Equipped Transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PEMD12 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PEMD13 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PEMD14 50 V, 100 mA NPN/PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PEMD15 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PEMD16 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PEMD18 EndOfLife
PEMD2 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PEMD20 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PEMD24 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PEMD3 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PEMD30 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = open Production
PEMD4 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = open Production
PEMD48 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ Production
PEMD6 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open Production
PEMD9 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PEMF21 12 V PNP loadswitch EndOfLife
PEMH1 NPN/NPN resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PEMH10 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PEMH11 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PEMH13 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 =  47 kΩ Production
PEMH14 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PEMH15 NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PEMH16 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PEMH18 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PEMH19 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open Production
PEMH2 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PEMH20 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PEMH24 NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm EndOfLife
PEMH30 NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open EndOfLife
PEMH4 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open Production
PIMC31 500 mA, 50 V NPN/PNP double resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMC31PA 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMC31PAS-Q 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMC32 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMC32-Q 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMC32PA 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMC32PAS-Q 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMD2 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PIMD3 NPN/PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PIMN31 500 mA, 50 V NPN/NPN double resistor-equipped transistor; R1 = 1 kOhm, R2 = 10 kOhm Production
PIMN31PA 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMN31PAS-Q 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMN32 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMN32-Q 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMN32PA 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMN32PAS-Q 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMP31 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 1 kΩ, R2 = 10 kΩ Production
PIMP31-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 1 kΩ, R2 = 10 kΩ Production
PIMP31PA 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMP31PAS-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMP32 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMP32-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMP32PA 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMP32PAS-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PQMB11 PNP/PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PQMD10 NPN/PNP resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PQMD12 NPN/PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ Production
PQMD13 NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PQMD16 NPN/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 47 kΩ Production
PQMD2 NPN/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ Production
PQMD3 NPN/PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PQMH10 NPN/NPN resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PQMH11 NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PQMH13 NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PQMH13-Q NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PQMH2 NPN/NPN resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ Production
PQMH9 NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PRMB11 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistors (RET) Production
PRMD10 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PRMD12 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PRMD13 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PRMD16 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PRMD2 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PRMD3 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PRMH10 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PRMH11 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PRMH13 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PRMH2 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PRMH9 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PUMB10 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMB11 50 V, 100 mA PNP/PNP resistor-equipped double transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PUMB11-Q 50 V, 100 mA PNP/PNP resistor-equipped double transistors; R1 = 10 kΩ, R2 = 10 kΩ Production
PUMB13 PNP/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PUMB13-Q PNP/PNP resistor-equipped double transistors; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PUMB2 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PUMB2-Q 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PUMB20 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PUMB24 50 V, 20 mA PNP/PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PUMB3 50 V, 100 mA PNP/PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PUMB3H 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open EndOfLife
PUMB3H-Q 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open Production
PUMB9 PNP/PNP double Resistor-Equipped Transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PUMD10 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMD10-Q NPN/PNP double Resistor-Equipped Transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMD12-Q NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PUMD13 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PUMD13-Q NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PUMD14 50 V, 100 mA NPN/PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PUMD15 NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PUMD15-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PUMD16 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PUMD16-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PUMD17-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PUMD18-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PUMD2 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PUMD2-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PUMD20 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PUMD24 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PUMD24-Q 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 kOhm, R2 = 100 kOhm Production
PUMD3 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PUMD3-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PUMD30 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = open Production
PUMD4 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = open Production
PUMD4-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = open Production
PUMD48 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMD48-Q NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMD6 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open Production
PUMD6-Q 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open Production
PUMD6H 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open EndOfLife
PUMD6H-Q 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open Production
PUMD9 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PUMD9-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PUMF11 NPN resistor-equipped transistor; PNP general purpose transistor EndOfLife
PUMF12 PNP general purpose transistor; NPN resistor-equipped transistor EndOfLife
PUMH1 NPN/NPN resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PUMH1-Q NPN/NPN resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PUMH10 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMH10-Q NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PUMH11 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PUMH11-Q 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PUMH13 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1= 4.7 kΩ, R2 = 47 kΩ Production
PUMH13-Q NPN/NPN double Resistor-Equipped Transistor (RET); R1= 4.7 kΩ, R2 = 47 kΩ Production
PUMH14 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PUMH14-Q 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PUMH15 NPN/NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PUMH16 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PUMH18 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PUMH19 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open Production
PUMH2 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PUMH2-Q 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PUMH20 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PUMH20-Q 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PUMH24-Q NPN/NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PUMH30-Q NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = open Production
PUMH4 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open Production
PUMH7H 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open EndOfLife
PUMH7H-Q 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open Production
Visit our documentation center for all documentation

Application note (1)
File name Title Type Date
AN90024.pdf Resistor Equipped Transistors (RETs): Key parameters and application insights Application note 2021-08-03

Brochure (1)
File name Title Type Date
Nexperia_document_brochure_DFN1412__diodes_transistors.pdf DFN1412-6 - a new (double) package standard Brochure 2022-09-21

Marcom graphics (1)
File name Title Type Date
DFN1006B-3_SOT883B_mk.png plastic, leadless ultra small plastic package; 3 solder lands; 0.35 mm pitch; 1 mm x 0.6 mm x 0.37 mm body Marcom graphics 2017-01-28

White paper (1)
File name Title Type Date
Nexperia_document_whitepaper_RET_devices_2021.pdf Nexperia document whitepaper RET devices 2021 White paper 2022-09-21

Please contact us if you have any questions. If you are in need of design support, please fill in the technical support form, we will get back to you shortly.

Please visit our community forum or contact us for further support.


Frequently Asked Questions

A RET is a Resistor Equipped Transistor. RETs combine the bias resistor and bias-emitter resistor in the same package as the transistor. Double RETs are devices that combine two transistors and two matching bias resistors and bias-emitter resistors.

Transistors and resistors are combined in one package. This

  • saves space
  • reduces pick and place costs
  • offers additional option for circuit design
  • reduces bom costs


Resistor equipped transistors (RETs) are also known as:

  • Digital transistors
  • Pre-Bias transistors
  • Built in resistor bipolar transistors

RETs can be used in:

  • Low side switch
  • High side switch
  • Push pull stage

RETs are suitable for use in numerous applications including:

  • Automotive
  • Industrial and Power
  • Communication
  • And many more

Nexperia offers more than 400 parts to chose from including:

  • 50 V RETs with 100 mA
  • 50 V RETs with 500 mA
  • 80 V RETs with 100 mA
  • 40 V with 600mA Low VCEsat RETs (Performance based RETs (PBR))

Within Nexperia’s RET portfolio you will find single and dual RETs with a great variety of resistor combinations.

Nexperia RETs are available in a wide range of leaded and leadless SMD packages:
Standard leaded SMD packages like SOT23, SOT323, SOT457, SOT223 as well as leadless SMD packages like the very small DFN1006-3 and DFN packages with side-wettable flanks like DFN1110D-3 and DFN1412D-3

Most of our products are qualified to AEC-Q101, please always check the datasheet.

A voltage swing of approx. 1.2 V is sufficient for switching the RET. Therefore, RETs can be easily driven directly by a micro controller.

Nexperia RETs have a state-of-the-art ratio tolerance of down to +-10% (PBR)


Nexperia is offering 80 V RETs that provide enough headroom for use in 48 V automotive board net (e.g. mild hybrid and EV cars) and other higher voltage circuits which are often subject to large spikes and pulses that previous 50 V parts cannot handle. The new series (NHDTx and NHUMx) includes 42 parts with PNP / NPN combinations. These come with the same bias resistor combinations as Nexperia’s 50 V parts. Devices have a 100 mA current capability and are AEC-Q101-approved.

Cross reference
