Recovery rectifiers

Fast recovery, space-saving devices

Our 200 - 650 V hyperfast (trr < 30 ns) and ultrafast (trr < 80 ns) recovery rectifiers deliver power density while minimizing reverse recovery time and loss. Housed in our automotive qualified copper clip-bond CFP package, these standard and fast recovery diodes deliver high current pulse capability and high power density with efficient switching in a space-saving footprint.

Key features and benefits

  • 1 mm package height for thin PCB designs
  • Up to 60% footprint savings - CFP compared to SMx
  • High current pulse capability due to solid copper clip-bond
  • High efficiency planar technology / High power density
  • Low magnetic inductance optimizes switching behavior
  • 200 V hyper-fast switching parts with optimized recovery time (trr) of < 20 ns
  • High speed switching capability
  • Low voltage drop (VF @ IF(max) ~ 1 V)
  • Low leakage current, also at high temperature
  • AEC-Q101 qualified parts (175 °C Tj (max))

Key applications

  • Polarity protection
  • DC/DC conversion
  • AC/DC conversion
  • Freewheeling of inductive load
  • Standard switching applications
  • High-speed switching applications
  • Engine and Transmission Control Unit
  • Solenoid control
  • Piezo injection

Latest news and blogs

  • Press release
Nov 21, 2022

Nexperia releases ultrafast 650 V Recovery ...
  • Press release
Oct 6, 2022

Nexperia Bolsters its Range of CFP Power Diodes
  • Press release
Sep 10, 2021

Nexperia surface-mount device passes Board Level ...

Latest videos

Maximize SMPS efficiency with Nexperia’s 200 V PNE recovery rectifier series

Maximize SMPS efficiency with Nexperia’s 200 V PNE recovery ...
Improve accuracy of AOI in PCB production by using modern ...
Improve accuracy of AOI in PCB production by using modern ...

Parametric search

Recovery rectifiers
Please wait loading data...
Parametric search is unavailable.

Products

Type number Description Status Quick access
ES1B 100 V, 1 A hyperfast recovery rectifier in SMA Production
ES1D 200 V, 1 A hyperfast recovery rectifier in SMA Production
ES1DR 200 V, 1 A hyperfast PN-rectifier EndOfLife
ES1DVR 200 V, 1 A hyperfast PN-rectifier EndOfLife
ES1GR 400 V, 1 A hyperfast switching time PN-rectifier EndOfLife
ES1J 600 V, 1 A hyperfast recovery rectifier in SMA Production
ES2D 200 V, 2 A hyperfast recovery rectifier in SMB Production
ES2DP 200 V, 2 A hyperfast PN-rectifier EndOfLife
ES2DR 200 V, 2 A hyperfast PN-rectifier EndOfLife
ES2DVR 200 V, 2 A hyperfast PN-rectifier EndOfLife
ES3D 200 V, 3 A hyperfast recovery rectifier in SMC Production
ES3DP 200 V, 3 A hyperfast PN-rectifier EndOfLife
FR2J 600 V, 2 A fast recovery rectifier in SMB Production
FR2JA 600 V, 2 A fast recovery rectifier in SMA Production
FR2M 1000 V, 2 A fast recovery rectifier in SMB Production
GS10M 1000 V, 10 A recovery rectifier in SMC Production
GS1M 1000 V, 1 A recovery rectifier in SMA Production
GS5MB 1000 V, 5 A recovery rectifier in SMB Production
GS8M 1000 V, 8 A recovery rectifier in SMC Production
MURS160A 600 V, 1 A ultrafast recovery rectifier in SMA Production
MURS160B 600 V, 1 A ultrafast recovery rectifier in SMB Production
PNE200100CPE 200 V, 2 x 5 A dual common cathode hyperfast recovery rectifier Production
PNE200100CPE-Q 200 V, 2 x 5 A dual common cathode hyperfast recovery rectifier Production
PNE200100EPE 200 V, 10 A hyperfast recovery rectifier Production
PNE200100EPE-Q 200 V, 10 A hyperfast recovery rectifier Production
PNE20010ER 200 V, 1 A hyperfast recovery rectifier Production
PNE20010ER-Q 200 V, 1 A hyperfast recovery rectifier Production
PNE20010EXD 200 V, 1 A hyperfast recovery rectifier Production
PNE20010EXD-Q 200 V, 1 A hyperfast recovery rectifier Production
PNE20020AER 200 V, 2 A hyperfast recovery rectifier Production
PNE20020AER-Q 200 V, 2 A hyperfast recovery rectifier Production
PNE20020EP 200 V, 2 A hyperfast recovery rectifier Production
PNE20020EP-Q 200 V, 2 A hyperfast recovery rectifier Production
PNE20020ER 200 V, 2 A hyperfast recovery rectifier Production
PNE20020ER-Q 200 V, 2 A hyperfast recovery rectifier Production
PNE20020EXD 200 V, 2 A hyperfast recovery rectifier Production
PNE20020EXD-Q 200 V, 2 A hyperfast recovery rectifier Production
PNE20030EP 200 V, 3 A hyperfast  recovery rectifier Production
PNE20030EP-Q 200 V, 3 A hyperfast  recovery rectifier Production
PNE20040CPE 200 V, 2 x 2 A dual common cathode hyperfast recovery rectifier Production
PNE20040CPE-Q 200 V, 2 x 2 A dual common cathode hyperfast recovery rectifier Production
PNE20040EP 200 V, 4 A hyperfast switching recovery rectifier Production
PNE20040EP-Q 200 V, 4 A hyperfast switching recovery rectifier Production
PNE20040EPE 200 V, 4 A hyperfast recovery rectifier Production
PNE20040EPE-Q 200 V, 4 A hyperfast recovery rectifier Production
PNE20050EP 200 V, 5 A hyperfast recovery rectifier Production
PNE20050EP-Q 200 V, 5 A hyperfast recovery rectifier Production
PNE20060CPE 200 V, 2 x 3 A dual common cathode hyperfast recovery rectifier Production
PNE20060CPE-Q 200 V, 2 x 3 A dual common cathode hyperfast recovery rectifier Production
PNE20060EPE 200 V, 6 A hyperfast recovery rectifier Production
PNE20060EPE-Q 200 V, 6 A hyperfast recovery rectifier Production
PNE20080CPE 200 V, 2 x 4 A dual common cathode hyperfast recovery rectifier Production
PNE20080CPE-Q 200 V, 2 x 4 A dual common cathode hyperfast recovery rectifier Production
PNE20080EPE 200 V, 8 A hyperfast recovery rectifier Production
PNE20080EPE-Q 200 V, 8 A hyperfast recovery rectifier Production
PNE650100EJ 650 V, 10 A hyperfast recovery rectifier Production
PNE650100EJ-Q 650 V, 10 A hyperfast recovery rectifier Production
PNE650150EJ 650 V, 15 A hyperfast recovery rectifier Production
PNE650150EJ-Q 650 V, 15 A hyperfast recovery rectifier Production
PNE650200EJ 650 V, 20 A hyperfast recovery rectifier Production
PNE650200EJ-Q 650 V, 20 A hyperfast recovery rectifier Production
PNS40010AER 400 V, 1 A high power density, standard switching time recovery rectifier Production
PNS40010AER-Q 400 V, 1 A high power density, standard switching time recovery rectifier Production
PNS40010ER 400 V, 1 A high power density, standard switching time recovery rectifier EndOfLife
PNU650100EJ 650 V, 10 A ultrafast recovery rectifier Production
PNU650100EJ-Q 650 V, 10 A ultrafast recovery rectifier Production
PNU65010EP 650 V, 1 A ultrafast recovery rectifier Production
PNU65010EP-Q 650 V, 1 A ultrafast recovery rectifier Production
PNU65010ER 650 V, 1 A ultrafast  recovery rectifier Production
PNU65010ER-Q 650 V, 1 A ultrafast recovery rectifier Production
PNU650150AEJ 650 V, 15 A ultrafast recovery rectifier Production
PNU650150AEJ-Q 650 V, 15 A ultrafast recovery rectifier Production
PNU650150EJ 650 V, 15 A ultrafast recovery rectifier Production
PNU650150EJ-Q 650 V, 15 A ultrafast recovery rectifier Production
PNU650200AEJ 650 V, 20 A ultrafast recovery rectifier Production
PNU650200AEJ-Q 650 V, 20 A ultrafast recovery rectifier Production
PNU650200EJ 650 V, 20 A ultrafast recovery rectifier Production
PNU650200EJ-Q 650 V, 20 A ultrafast recovery rectifier Production
PNU65020EP 650 V, 2 A ultrafast recovery rectifier Production
PNU65020EP-Q 650 V, 2 A ultrafast recovery rectifier Production
PNU650300AEJ 650 V, 30 A ultrafast recovery rectifier Production
PNU650300AEJ-Q 650 V, 30 A ultrafast recovery rectifier Production
PNU65030EP 650 V, 3 A ultrafast recovery rectifier Production
PNU65030EP-Q 650 V, 3 A ultrafast recovery rectifier Production
S1DR 200 V, 1 A high power density, standard switching time PN-rectifier EndOfLife
US1J 600 V, 1 A ultrafast recovery rectifier in SMA Production
US1M 1000 V, 1 A ultrafast recovery rectifier in SMA Production
US3M 1000 V, 3 A ultrafast recovery rectifier in SMC Production
Visit our documentation center for all documentation

Brochure (2)
File name Title Type Date
Nexperia_document_brochure_Recovery_rectifier.pdf Hyperfast recovery, space-saving devices Brochure 2024-05-08
Nexperia_document_brochure_Recovery_rectifier_CN_2022.pdf 恢复整流器 Brochure 2023-03-29

Data sheet (4)
File name Title Type Date
PNU65010ER.pdf 650 V, 1 A ultrafast  recovery rectifier Data sheet 2025-03-11
PNU65010ER-Q.pdf 650 V, 1 A ultrafast recovery rectifier Data sheet 2025-03-11
PNU65010EP.pdf 650 V, 1 A ultrafast recovery rectifier Data sheet 2025-03-11
PNU65010EP-Q.pdf 650 V, 1 A ultrafast recovery rectifier Data sheet 2025-03-11

Leaflet (1)
File name Title Type Date
NEX_173_Leaflet-PackageStrategy_update_v01_2023.pdf NEX_173_Leaflet - Package Strategy update v01 (2) Leaflet 2023-11-22

Marcom graphics (1)
File name Title Type Date
CFP3_SOD123W_mk.png plastic, surface mounted package; 2 terminals; 2.6 mm x 1.7 mm x 1 mm body Marcom graphics 2017-01-28
