NextPowerS3 MOSFETs

Safe, Reliable and Efficient

A high-performance 25 V, 30 V and 40 V MOSFET platform incorporating Nexperia’s unique superjunction technology, with the copper-clip LFPAK package to deliver low RDS(on), as well as demonstrating a continuous current capability up to 425 A. These parameters working synchronously, i.e. strong/realistic ID max rating, very strong SOA and low RDS(on) making for uniquely positioned high performance and highly reliable MOSFETs without compromise.

Features and Benefits

  • Balanced RDS(on) and Qg for class leading efficiency
  • Unique Schottky-Plus technology delivers low spiking without compromising efficiency or IDSS leakage.
  • High reliability LFPAK packages. Copper clip, solder die attach and qualified to 175°C.
  • 425 A continuous current demonstrated.
  • 4x SOA capability compared to leading competitors.

Applications

  • Low RDS(on) types for power ORing, hotswap and soft start.
  • DC to DC solutions for server and telecoms.
  • Voltage regulator modules (VRM).
  • Point of Load (PoL) modules.
  • Secondary side synchronous rectification.
  • Brushed and brushless motor control.

Featured products

PSMNR51-25YLH

PSMNR51-25YLH

N-channel 25 V, 0.57 mΩ, 380 A LL MOSFET in LFPAK56E
PSMN1R7-40YLB

PSMN1R7-40YLB

N-channel 40 V, 1.8 mΩ, 200 A. LL MOSFET in LFPAK56 optimised for EMC
PSMNR55-40SSH

PSMNR55-40SSH

N-channel 40 V, 0.55 mOhm, 500 Amps continuous, standard level MOSFET in ...

Featured documents

Understanding power MOSFET data sheet parameters

Understanding power MOSFET data sheet parameters

AN11158
Using RC Thermal Models

Using RC Thermal Models

AN11261
LFPAK MOSFET thermal design guide

LFPAK MOSFET thermal design guide

AN90003

Latest news and blogs

  • Press release
Mar 21, 2019

Nexperia announces lowest RDS(on) MOSFETs in ...
  • Blog article
Oct 31, 2019

Is today’s accepted MOSFET Figure of Merit still ...
  • Blog article
Mar 17, 2019

Seeking the perfect power switch

Latest videos

Design considerations with sub-milliohm MOSFETs – Quick Learning

Design considerations with sub-milliohm MOSFETs – Quick Learning
The importance of SOA - Quick Learning
Using Nexperia Power MOSFETs to handle high currents up to 380 A
High current 3-phase BLDC motor drive application using ...
MOSFETs with extraordinary SOA for industrial applications
MOSFETs for use in high continuous current application
Motor control in battery powered products and key MOSFET ...

Parametric search

NextPowerS3 MOSFETs
Please wait loading data...
Parametric search is unavailable.

Products

MOSFETs

Type number Description Status Quick access
PSMN014-40HLD N-channel 40 V, 13.6 mOhm, logic level MOSFET in LFPAK56D using NextPowerS3 technology Production
PSMN0R7-25YLD N-channel 25 V, 0.72 mΩ, 300 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN0R9-25YLD N-channel 25 V, 0.85 mΩ, 300 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN0R9-30YLD N-channel 30 V, 0.87 mΩ, 300 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R0-25YLD N-channel 25 V, 1.0 mΩ, 240 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R0-30YLD N-channel 30 V, 1.0 mΩ, 300 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R0-40SSH N-channel 40 V, 1 mΩ, 325 Amps continuous, standard level MOSFET in LFPAK88 using NextPowerS3 Technology Production
PSMN1R0-40YLD N-channel 40 V, 1.1 mΩ, 280 A logic level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN1R0-40YSH N-channel 40 V, 1 mΩ, 290 A standard level MOSFET in LFPAK56E using NextPower-S3 Schottky-Plus technology Production
PSMN1R2-25YLD N-channel 25 V, 1.2 mΩ, 230 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R2-30YLD N-channel 30 V, 1.2 mΩ, 250 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R4-30YLD N-channel 30 V, 1.4 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R4-40YLD N-channel 40 V, 1.4 mΩ, 240 A logic level MOSFET in LFPAK56 using NextPower-S3 technology Production
PSMN1R4-40YSH N-channel 40 V, 1.4 mOhm, 240 A standard level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN1R5-25MLH N-channel 25 V, 1.81 mΩ, 150 A logic level MOSFET in LFPAK33 using NextPowerS3 technology Production
PSMN1R5-40YSD N-channel 40 V, 1.5 mΩ, 240 A standard level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN1R6-30MLH N-channel 30 V, 1.9 mΩ, 160 A logic level MOSFET in LFPAK33 using NextPowerS3 technology Production
PSMN1R7-25YLD N-channel 25 V, 1.75 mOhm, 200 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN1R7-40YLB N-channel 40 V, 1.8 mOhm, 200 A logic level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN1R7-40YLD N-channel 40 V, 1.8 mΩ, 200 A logic level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN1R8-30MLH N-channel 30 V, 2.1 mΩ, 150 A logic level MOSFET in LFPAK33 using NextPowerS3 technology Production
PSMN1R9-40YSB N-channel 40 V, 1.9 mOhm, 200 A standard level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN1R9-40YSD N-channel 40 V, 1.9 mΩ, 200 A standard level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN2R0-25MLD N-channel 25 V, 2.1 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN2R0-25YLD N-channel 25 V, 2.09 mΩ, 179 A logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN2R0-40YLB N-channel 40 V, 2.1 mOhm, 180 A logic level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN2R0-40YLD N-channel 40 V, 2.1 mΩ, 180 A logic level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN2R2-40YSB N-channel 40 V, 2.2 mOhm, 180 A standard level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN2R2-40YSD N-channel 40 V, 2.2 mΩ, 180 A standard level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN2R4-30MLD N-channel 30 V, 2.4 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN2R4-30YLD N-channel 30 V, 2.4 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN2R5-40YLB N-channel 40 V, 2.6 mOhm, 160 A logic level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN2R5-40YLD N-channel 40 V, 2.6 mΩ, 160 A logic level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN2R8-40YSB N-channel 40 V, 2.8 mOhm, 160 A standard level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN2R8-40YSD N-channel 40 V, 2.8 mΩ, 160 A standard level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN3R0-30YLD N-channel 30 V, 3.0 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN3R2-40YLB N-channel 40 V, 3.3 mOhm, 120 A logic level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN3R2-40YLD N-channel 40 V, 3.3 mΩ, 120 A logic level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN3R5-25MLD N-channel 25 V, 3.72 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN3R5-40YSB N-channel 40 V, 3.5 mOhm, 120 A standard level MOSFET in LFPAK56 using optimized NextPowerS3 Schottky-Plus technology Production
PSMN3R5-40YSD N-channel 40 V, 3.5 mΩ, 120 A standard level MOSFET in LFPAK56 using NextPower-S3 Schottky-Plus technology Production
PSMN4R0-30YLD N-channel 30 V, 4.0 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN4R2-30MLD N-channel 30 V, 4.2 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN5R3-25MLD N-channel 25 V, 5.3 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN5R4-25YLD N-channel 25 V, 5.69 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN6R0-25YLD N-channel 25 V, 6.75 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN6R0-30YLD N-channel 30 V, 6.0 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN6R1-25MLD N-channel 25 V, 6.8 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN6R1-30YLD N-channel 30 V, 6.1 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMN7R5-30MLD N-channel 30 V, 7.5 mΩ logic level MOSFET in LFPAK33 using NextPowerS3 Technology Production
PSMN7R5-30YLD N-channel 30 V, 7.5 mΩ logic level MOSFET in LFPAK56 using NextPowerS3 Technology Production
PSMNR51-25YLH N-channel 25 V, 0.57 mΩ, 380 A logic level MOSFET in LFPAK56E using NextPowerS3 technology Production
PSMNR58-30YLH N-channel 30 V, 0.67 mΩ, 380 A logic level MOSFET in LFPAK56E using NextPowerS3 technology Production
PSMNR60-25YLH N-channel 25 V, 0.7 mΩ, 300 A logic level MOSFET in LFPAK56 using NextPowerS3 technology Production
PSMNR70-30YLH N-channel 30 V, 0.82 mΩ, 300 A logic level MOSFET in LFPAK56 using NextPowerS3 technology Production
PSMNR70-40SSH N-channel 40 V, 0.7 mΩ, 425 Amps continuous, standard level MOSFET in LFPAK88 using NextPowerS3 Technology Production
PSMNR70-40YSN N-channel 40 V, 0.81 mOhm, 320 A standard level MOSFET in LFPAK56E using NextPower-S3 Schottky-Plus technology Development
PSMNR90-40YLH N-channel 40 V, 0.94 mΩ, 300 A logic level MOSFET in LFPAK56E using NextPower-S3 Schottky-Plus technology Production

Documentation

File name Title Type Date
AN11158 Understanding power MOSFET data sheet parameters Application note 2020-07-06
AN11261 RC Thermal Models Application note 2021-03-18
AN90003 LFPAK MOSFET thermal design guide Application note 2023-08-22
NextPowerS3_cleaner_image NextPowerS3 cleaner image Marcom graphics 2020-01-23
