Key features and benefits
- N-channel and P-channel versions available
- 2N7002 functionality in DFN0606
- ESD protection of up to 2 kV
- Ultra-small 0.62 x 0.62 mm footprint
- Low height of only 0.37 mm
- Large portfolio in plan
- Standard switch for mobile and portable products
- Level translator
- 0.35 mm pitch
- Leadless ultra small package DFN0606-3
- Ultra-thin package with 0.37 mm height
Space saving package with minimal assembly adjustment
Featured products
Featured documents
Products
Automotive qualified products (AEC-Q100/Q101)
| Type number | Description | Status | Quick access |
|---|---|---|---|
| 2N7002BKM | 60 V N-channel Trench MOSFET | Not for design in | |
| BSS84AKM | 50 V, 230 mA P-channel Trench MOSFET | Production |
MOSFETs
| Type number | Description | Status | Quick access |
|---|---|---|---|
| 2N7002BKM | 60 V N-channel Trench MOSFET | Not for design in | |
| 2N7002BKMB | 60 V, single N-channel Trench MOSFET | Not for design in | |
| BSS84AKM | 50 V, 230 mA P-channel Trench MOSFET | Production | |
| BSS84AKMB | 50 V, single P-channel Trench MOSFET | Production | |
| NX138AKM | 60 V, N-channel Trench MOSFET | Production | |
| NX138BKM | 60 V, N-channel Trench MOSFET | Production | |
| NX3008NBKMB | 30 V, single N-channel Trench MOSFET | Not for design in | |
| NX5008NBKM | 50 V, N-channel Trench MOSFET | Production | |
| NX7002BKM | 60 V, N-channel Trench MOSFET | Production | |
| NX7002BKMB | 60 V, N-channel Trench MOSFET | Production | |
| PMZ1000UN | N-channel TrenchMOS standard level FET | Not for design in | |
| PMZ1200UPE | 30 V, P-channel Trench MOSFET | Production | |
| PMZ130UNE | 20 V, N-channel Trench MOSFET | Production | |
| PMZ200UNE | 30 V, N-channel Trench MOSFET | Production | |
| PMZ290UNE | 20 V, N-channel Trench MOSFET | Not for design in | |
| PMZ290UNE2 | 20 V, N-channel Trench MOSFET | Production | |
| PMZ320UPE | 30 V, P-channel Trench MOSFET | Production | |
| PMZ350UPE | 20 V, P-channel Trench MOSFET | Production | |
| PMZ370UNE | 30 V, N-channel Trench MOSFET | Not for design in | |
| PMZ390UN | 30 V, N-channel Trench MOSFET | Not for design in | |
| PMZ390UNE | 30 V, N-channel Trench MOSFET | Production | |
| PMZ550UNE | 30 V, N-channel Trench MOSFET | Production | |
| PMZ600UNE | 20 V, N-channel Trench MOSFET | Production | |
| PMZ600UNEL | 20 V, N-channel Trench MOSFET | Production | |
| PMZ950UPE | 20 V, P-channel Trench MOSFET | Production | |
| PMZ950UPEL | 20 V, P-channel Trench MOSFET | Production | |
| PMZB1200UPE | 30 V, P-channel Trench MOSFET | Production | |
| PMZB150UNE | 20 V, N-channel Trench MOSFET | Production | |
| PMZB200UNE | 30 V, N-channel Trench MOSFET | Production | |
| PMZB290UN | 20 V, single N-channel Trench MOSFET | Not for design in | |
| PMZB290UNE2 | 20 V, N-channel Trench MOSFET | Production | |
| PMZB320UPE | 30 V, P-channel Trench MOSFET | Production | |
| PMZB350UPE | 20 V, single P-channel Trench MOSFET | Production | |
| PMZB390UNE | 30 V, N-channel Trench MOSFET | Production | |
| PMZB550UNE | 30 V, N-channel Trench MOSFET | Production | |
| PMZB600UNE | 20 V, N-channel Trench MOSFET | Production | |
| PMZB600UNEL | 20 V, N-channel Trench MOSFET | Production | |
| PMZB670UPE | 20 V, single P-channel Trench MOSFET | Not for design in | |
| PMZB950UPE | 20 V, P-channel Trench MOSFET | Production | |
| PMZB950UPEL | 20 V, P-channel Trench MOSFET | Production |
Documentation
| File name | Title | Type | Date |
|---|---|---|---|
| nexperia_report_aoi_inspection_dfn_201808 | Automatic Optical Inspection of DFN Components | Report | 2018-09-03 |
| DFN0606_SOT8001_mk | plastic, leadless ultra small package; 3 terminals; body 0.62 x 0.62 x 0.37 mm | Marcom graphics | 2019-07-29 |
| nexperia_document_leaflet_DFN0606_LR_2020 | DFN0606 | Leaflet | 2020-04-15 |
| nexperia_document_leaflet_DFN0606_CHN_2020 | DFN0606 Chinese Translation | Leaflet | 2020-04-15 |
| nexperia_document_leaflet_SsMOS_for_mobile_2022 | High volume small-signal MOSFETs for mobile and portables, in WLCSP and leadless DFN packages | Leaflet | 2022-07-04 |
| nexperia_document_leaflet_SsMOS_for_mobile_2022-CHN | 适合移动和便携式设备的 大批量小信号MOSFET， 采用WLCSP和无引脚DFN封装 | Leaflet | 2022-07-04 |
