eFuse

Integrated power path protection devices for hot-swap applications

Electronic Fuses (eFuses) are protection devices designed for hot-swap applications, featuring a built-in pass transistor in thermally optimized packages. eFuses combine several protection functions, including overvoltage protection, inrush current control, output overload protection, and device overtemperature protection. This integration not only enhances the system's robustness but also minimizes the solution size. Additionally, these features can be easily customized to suit various applications, often requiring only a few external components.

Key features:

  • Wide input voltage range making it versatile for various applications
  • Integrated low resistance pass transistor to ensure efficient operation
  • Over voltage protection to safeguard against input voltage spikes
  • Inrush current control to enhance system reliability
  • Output overload protection to protect the power supply
  • Over temperature protection to ensure device safety

Key applications:

  • Solid State Drives (SSD) and Hard Disk Drives (HDD)
  • Laptops
  • Servers, datacenters
  • Set Top Boxes (STB)
  • Ethernet switches and routers
  • Industrial automation
  • Mobile infrastructure
  • Fan control

Products

Type number Description Status Quick access
NPS3102 12 V, 2 A to 13.5 A, 17 mΩ eFuse ACT
NPS3102AGB 12 V, 2 A to 13.5 A, 17 mΩ eFuse Qualification
NPS3102BGB 12 V, 2 A to 13.5 A, 17 mΩ eFuse Qualification
NPS3102AGB 12 V, 2 A to 13.5 A, 17 mΩ eFuse Qualification
NPS3102BGB 12 V, 2 A to 13.5 A, 17 mΩ eFuse Qualification
Visit our documentation center for all documentation

Data sheet (1)

File name Title Type Date
NPS3102.pdf 12 V, 2 A to 13.5 A, 17 mΩ eFuse Data sheet 2024-07-18

Leaflet (1)

File name Title Type Date
nexperia_documentation_leaflet_.pdf 12 V, 2 A-13.5 A (17 mΩ) eFuse Leaflet 2024-07-19

Outline 3d (1)

File name Title Type Date
sot355-1_3d.png plastic, thin shrink small outline package; 24 leads; 0.65 mm pitch; 7.8 mm x 4.4 mm x 1.1 mm body Outline 3d 2021-06-10
