Low capacitance ESD protection for high-speed interfaces

Overcoming sensitivity to ESD and other voltage-induced transient pulses

High speed interfaces tolerate very little additional capacitance on the line, however miniaturization makes them increasingly sensitive to ESD strikes. To help you overcome this dilemma, we offer a variety of ultra-low capacitance ESD protection diodes to match all your design requirements. These advanced solutions improve design efficiency, maximizing PCB design flexibility while occupying minimum PCB space.

Key features and benefits

  • Ultra low diode capacitance down to Cd = 0.4 pF typ.
  • ESD protection of ultra high-speed applications
  • Single line, multiline arrays and rail-to-rail configurations
  • Maximum PCB design flexibility
  • Ultra low leakage current down to... IRM = 5 nA
  • Minimum PCB area requirements
  • Ultra small packages
  • Very low clamping voltages compared to varistors
  • IEC 61000-4-2; level 4 (ESD), and AECQ101 qualified

Key applications

  • Portable electronics including cellular handsets and accessories
  • Audio and video equipment
  • Antenna protection
  • USB interfaces
  • High-speed data lines
